Introduction

Principle & Structure

KAP50 is based on ceramic capacitor technology. When the pressure increases, the pressure value applied to the ceramic capacitor increases, making the capacitance value increase, and the capacitance value is proportional to the pressure value.

Features

● Flange installation, strong overload capacity

● Good stability, due to 0.1% of full scale per year

● Long life, can be used for continuous monitoring of liquid level

● Strong anti-interference ability, extremely high precision and repeatability can reach 0.2, 0.5 grades

● 4-20mA/1-5 analog output optional;

● The zero point and full scale can be adjusted on site. The ceramic measuring interface has good corrosion resistance.

application

Suitable for pressure monitoring of medium and large tanks. It is suitable for viscous and slurry-like media, strong corrosive liquids, and particulate-rich media, and is not easy to block. Mainly used in wastewater / water purification, shipbuilding, generator equipment, petrochemical, food, electronics, dyeing and finishing, chemistry, rubber and plastics, hydraulic machinery, chemical and pharmaceutical industries.

technical parameter

Measuring range:0…0.1bar to 0…40bar
Accuracy class:0.2% or 0.5%
Linearity:±0.2% or ±0.5%
Hysteresis:≤±0.01% of full scale
Temperature effects:Tk<±0.02%FS/K
Range shift:10:1 migration of standard range
Operating Voltage:12…36V DC
Load Resistance:≤1000Ω
Operating temperature:-30…85℃
Medium temperature:-30…80℃
storage temperature:-30…85℃
Flange Specifications:DN50 PN4.0MPa
DN80 PN4.0MPa
Protection class:IP65
Transmitter Housing Material:Die-cast aluminum
Flange Material:Stainless steel 316L/polytetrafluoroethylene (PTFE) optional
Enclosure rating:IP65

Selection table

KAP50-Capacitive Pressure Transmitter

range

Gauge pressure (for the range, see the range code table, this item is for general application selection)

show header

No display header

LCD display meter

Accuracy class

0.20% (Level 0.2)

0.50% (level 0.5)

Analog signal output

4…20mA current signal

1…5V voltage signal

Connection method

Flange connection: DN50

Flange connection: DN80

Threaded connection: M42×1.5
The complete data of this selection table, please contact the sales staff or email to sales@kewill-auto.cn for complete samples.
